CASE STUDY 12.0
Cyclone / Grit arrestor
New bespoke cyclone / grit arrestor, designed, manufactured, and supplied by Thorne International Boiler Services Ltd. in 2022 to a UK based biomass plant as part of an upgrade project.
Specification
Duty [flue gas]
Operating temperature
Year of manufacture
Industry
Scope of supply
59,040 kg/h
400 / 200 °C
2022
Biomass
Cyclone
Supporting steel | Access platforms | Flue gas ducting | Ash discharge valve Integration into plant
- Cyclone designed to receive flue gas at 400°C from an existing upstream wood-fired combustor and remove solid particulates for discharge to ash system.
Cyclone designed in accordance with TIBS standards.
3D scan of area completed to ensure successful integration into available space and flue gas ducting connection.
Supplied together with air-to-air heat exchanger, flue gas ducting integration into existing ducting system, structural supporting steelwork, and access platforms.
Supplied by Thorne International Boiler Services Ltd., including installation,
commissioning and testing.
